Hikvision 24-Port PoE Switch
Hikvision 24-Port PoE Switch
Regular price
Rs. 18,999.00 INR
Regular price
Sale price
Rs. 18,999.00 INR
Taxes included.
Shipping calculated at checkout.
Professional 24-Port PoE Switch for CCTV & Security Networks
Power and connect up to 24 IP cameras, wireless access points, and network devices with the Hikvision DS-3E0326P-E/M 24-Port PoE Switch. Designed specifically for surveillance systems and security installations, this unmanaged PoE switch delivers reliable power distribution, long-range transmission, surge protection, and stable network performance for demanding environments.
With 24 PoE-enabled ports, Gigabit uplink connectivity, and fiber uplink support, the switch simplifies CCTV deployments while reducing cabling costs. Intelligent PoE management automatically protects the switch and connected devices from power overload situations.
Key Features
- ✅ 24 × 10/100 Mbps PoE Ports
- ✅ 1 × Gigabit RJ45 Uplink Port
- ✅ 1 × Gigabit SFP Fiber Uplink Port
- ✅ IEEE 802.3af / 802.3at PoE Support
- ✅ Up to 30W PoE Output Per Port
- ✅ Total PoE Budget up to 230W
- ✅ Intelligent PoE Power Management
- ✅ Up to 300m Long-Range PoE Transmission
- ✅ 6kV Surge Protection
- ✅ VIP High-Priority Ports for Critical Cameras
- ✅ Fanless Industrial Design
- ✅ Plug-and-Play Installation
- ✅ Durable Metal Housing
Perfect For
- CCTV Surveillance Systems & NVR Camera Networks
- Commercial Buildings, Warehouses & Industrial Security Projects
- Schools, Colleges, Hotels & Resorts
- Retail Stores & Smart Home Installations
Benefits
- Power and data over a single Ethernet cable
- Supports large CCTV deployments up to 24 cameras
- Extended transmission distance up to 300 meters
- Protects equipment against voltage surges
- Ensures priority transmission for critical security cameras
- Reduces installation complexity and wiring costs
- Reliable 24/7 operation for surveillance environments
- Easy deployment with no configuration required
Technical Specifications
| Specification | Details |
|---|---|
| PoE Ports | 24 × 10/100 Mbps RJ45 |
| Uplink Ports | 1 × Gigabit RJ45 |
| Fiber Port | 1 × Gigabit SFP |
| PoE Standard | IEEE 802.3af / 802.3at |
| Max PoE Output | 30W Per Port |
| Total PoE Budget | 230W |
| Switching Capacity | 8.8 Gbps |
| Packet Forwarding Rate | 6.547 Mpps |
| MAC Address Table | 4K |
| Long Range Mode | Up to 300m |
| Surge Protection | 6kV |
| Housing | Metal |
| Power Supply | 100–240V AC |
| Dimensions | 335 × 226 × 44.5 mm |
| Weight | 2.55 kg |
Specifications sourced from Hikvision product documentation.
Package Includes
- 1 × Hikvision DS-3E0326P-E/M PoE Switch
- Power Cable
- Rack Mount Accessories
- User Manual
Warranty
2-Year Manufacturer Warranty
